All your fieldphones are belong to us

Or let's say at least most.

Below a comparison table of all army field telephones I'm currently aware of (150+ and growing). From 1898 to 2000+, from 1 to 12kg and from A(rgentina) to Y(ugoslavia).

Out of scope and caveats

Comparison table

The default sorting is per year, by clicking on the specific column header you can sort e.g. per country or per weight. Table key below.

Push the button to download the table as

Year Country Name Type Size [mm] Weight [kg] Enclosing Body/Chassis Battery Ringer Generator Buzzer Handset Headset Laryngo phone Dial Waterproof Circuit Notes Make In My Collection Original Document Webpage
1898 GB C Mk I LB 305x170x210 7 Wood Wood 2x 1,5V RK190 ● ● ⁃ ● ⁃   ⁃ ⁃ P/S Ericsson No 390 / MB100 - [8] Ericsson Link   Link
1901 USA Field Telephone Model 1901 LB     Wood   2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link Link
1904 Germany Feldfernsprecher LB 340x155x195 10.6 Wood Wood Ext. ● ● ● ● ○   ⁃ ⁃ Induction coil/Buzzer combined Weight without Battery: 8 Siemens & Halske Link Link Link
1904 USA Field Telephone Model 1904 LB     Wood   2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link Link
1905 USA Service Buzzer LB 216x216x216 4 Wood   4x 1,5V ⁃ ⁃ ● ⁃ ●   ⁃ ⁃ Induction coil/Buzzer combined       Link Link
1905 USA Field Buzzer LB     Leather   5x 1,5V ⁃ ⁃ ● ⁃ ●   ⁃ ⁃ Induction coil/Buzzer combined       Link Link
1905 Germany Armeefernsprecher LB 300x120x120 5.1 Leather Light alloy Ext. ⁃ ⁃ ● ● ○   ⁃ ⁃ Induction coil/Buzzer combined Weight without Battery: 2.5 Siemens & Halske Link Link Link
1905 Sweden M/05 LB 305x170x210 8 Wood Wood 2x 1,5V RK190 ● ● ● ● ⁃   ⁃ ⁃ P/S Ericsson MB 200 Ericsson     Link
1907 Austria-Hungary Mikrophonkassette M07 LB 275x110x195 4 Wood Wood Ext. ⁃ ⁃ ● ● ●   ⁃ ⁃ Induction coil/Buzzer combined Is also a 4 line switchboard   Link Link Link
1908 Austria-Hungary Patroullienapparat M08 LB     Leather Light alloy Ext. ⁃ ⁃ ● ● ○   ⁃ ⁃ Induction coil/Buzzer combined Similar to German Armeefernsprecher       Link
1908 USA Field Buzzer 1908 LB 220x150x170 4 Leather   5x 1,5V ⁃ ⁃ ● ⁃ ●   ⁃ ⁃ Induction coil/Buzzer combined       Link Link
1908 GB C Mk II LB     Wood   2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S [8]       Link
1908 GB D Mk I LB 190x100x190 3.6 Leather Wood 1x 1,5V RK150 ● ● ⁃ ● ⁃   ⁃ ⁃ P/S Ericsson No 392 / MB300 Ericsson     Link
1908 Sweden M/08 LB 250x70x175 3.7 Leather Fibre 1x 3V RK170 ● ● ● ● ●   ⁃ ⁃ P/S Ericsson MA 200 Ericsson     Link
1908 France Poste Microtéléphonique Modèle 1908 LB Leather Wood 2x 1,5V TM No1 ⁃ ⁃ ● ● ●   ⁃ ⁃ P/S       Link
1909 Italy Mod. Anzalone LB 165x80x220 3.5 Leather Wood 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link
1909 Russia M1909 LB 305x115x270 8.8 Leather Wood 2x 1,5V ● ⁃ ● ● ⁃   ⁃ ⁃ P/S       Link
1909 Sweden M/09 LB 210x75x160 2.5 Leather Fibre 1x 3V RK180 ● ⁃ ● ● ●   ⁃ ⁃ P/S Ericsson MA 80 Ericsson     Link
1909 Switzerland Feldtelefon LB/CB 320x145x260 8.7 Leather Wood 2x 1,5V IEC S4 - ● ● ● ●   ⁃ ⁃ P/S Some: Induction coil/Buzzer combined Siemens & Halske Link Link Link
1909 Denmark M. 1909/14 LB   7.7 Leather Wood 3V ● ● ● ● ● ⁃ ⁃ ⁃ P/S Is also a 4 line switchboard     Link
1909 France TM 09 LB 10 Leather Wood 2x 1,5V TM No1 ● ● ● ● ●   ⁃ ⁃ P/S         Link
1910 Austria-Hungary Tragbare Mikrotelephonstation M10 LB     Wood Wood 2x 1,5V IEC S4 ● ● ⁃ ● ⁃   ⁃ ⁃ P/S   Siemens & Halske     Link
1910 USA Cavalry Buzzer LB 1.8 Leather   3V ⁃ ⁃ ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined Ericsson type 394 / MA 10     Link Link
1910 USA Field Telephone Model 1910 LB     Wood   2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link Link
1910 USA Field Artillery Telephone Model 1910 LB 80x180x200 3 Wood   2x 3V ⁃ ⁃ ● ⁃ ●   ⁃ ⁃ Induction coil/Buzzer combined       Link Link
1911 GB Stevens' LB 170x95x160 2.8 Leather Metal 4x 1,5V Size S/X ⁃ ⁃ ● ● ●   ⁃ ⁃ Induction coil/Buzzer combined [8] International Electric Company Ltd. Kilburn   Link
1912 Sweden M/12 LB 250x100x180 4.2 Leather Fibre 1x 3V RK170 ● ● ● ● ●   ⁃ ⁃ P/S Ericsson MA 210 Ericsson Yes   Link
1913 Germany Eiserner Armeefernsprecher LB 300x120x120 5 Leather Steel Ext. ⁃ ⁃ ● ● ○   ⁃ ⁃ Induction coil/Buzzer combined Weight without Battery: 2.4 Siemens & Halske Yes Link Link
1913 Germany Eiserner Feldfernsprecher LB 340x155x195 11.5 Wood Wood Ext. ● ● ● ● ○   ⁃ ⁃ Induction coil/Buzzer combined Weight without Battery: 8.9 Siemens & Halske Yes Link Link
1913 Switzerland Central Telefon LB/CB 320x140x210 9.2 Wood Wood 2x 1,5V IEC S4 ● ● ● ● ●   ⁃ ⁃ P/S Some: Induction coil/Buzzer combined Siemens & Halske Link Link Link
1913 USA Camp Telephone LB 180x115x250 5 Wood Aluminum 1x 3V BA-1 ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link Link
1914 USA Service Buzzer (EE-63) LB 100x135x190 1.5 Leather   2x BA-1 3V ⁃ ⁃ ● ⁃ ●   ⁃ ⁃ Induction coil/Buzzer combined Got later designation EE-63   Link Link Link
1914 Russia M1914 LB 295х100x235 4 Wood Wood 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link Link
1914 GB D Mk II LB   2.5 Leather Metal 2x 1,5V Size S/X ⁃ ⁃ ● ● ●   ⁃ ⁃ Induction coil/Buzzer combined       Link
1914 France Poste Microtéléphonique Modèle 1914 LB Leather Wood 2x 1,5V TM No1 ⁃ ⁃ ● ⁃ ●   ⁃ ⁃ P/S       Link Link
1915 GB D Mk III LB     Leather Metal 2x 1,5V Size S/X ● ⁃ ● ● ●   ⁃ ⁃ Induction coil/Buzzer combined [8]     Link Link
1915 Switzerland Zerlegbares Telefon LB 230x185x175 4.3 Leather Wood 2x 1,5V IEC S4 ⁃ ⁃ ● ● ○   ⁃ ⁃ P/S Size without handset Hasler Link   Link
1915 Switzerland Artillerietelefon LB/CB 320x130x250 6.4 Wood Wood 2x 1,5V IEC S4 ⁃ ⁃ ● ● ●   ⁃ ⁃ P/S Some: Induction coil/Buzzer combined Siemens & Halske Link Link Link
1915 France TM 09-15 (Timmimoum) LB 250x145x190 7 Leather Wood 2x 1,5V TM No1 ● ● ● ● ●   ⁃ ⁃ P/S Improved, lighter version fo TM 09     Link Link
1915 France Modèle S.I.T. 144 (-4/6/8) LB     Wood Wood 2x 1,5V TM No0 ● ● ● ● ⁃   ⁃ ⁃ P/S Only type 144-8 has a buzzer Société Industrielle des Téléphones   Link Link
1916 Austria-Hungary Fernsprechstelle M16 LB 260x100x240 3.6 Canvas Metal 2x 1,5V ⁃ ⁃ ● ● ●   ⁃ ⁃ Induction coil/Buzzer combined         Link
1916 Austria-Hungary Fernsprechstelle M10/16 LB     Wood Wood 2x 1,5V IEC S4 ● ● ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined   Siemens & Halske     Link
1916 France TM 16 LB 228x219x169   Wood Wood 2x 1,5V TM No0 ● ● ● ● ●   ⁃ ⁃ P/S Buzzer is magneto operated (not battery dependant)   Yes Link Link
1916 Germany Feldfernsprecher 16 LB 340x155x200 9 Wood Wood 2x 1,5V IEC S4 ● ● ● ● ○   ⁃ ⁃ Induction coil/Buzzer combined     Yes   Link
1916 Italy Modell 1916 LB 240x170x175 7 Wood Wood 1x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S     Yes   Link
1916 Russia M1916 LB 305х150x205 6.3 Wood Wood 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ P/S   Nippon Electric co., Japan   Link Link
1917 Germany (Grosser) Feldfernsprecher 17 LB 280x100x225 7 Wood Wood 2x 1,5V IEC S4 ● ● ○ ● ○   ⁃ ⁃ P/S     Yes   Link
1917 Germany Kleiner Feldfernsprecher 17 LB     Wood Wood 2x 1,5V IEC S4 ⁃ ⁃ ○ ● ○   ⁃ ⁃ P/S     Yes   Link
1917 USA Camp Telephone Model 17 (EE-4-A) LB 195x130x250 8.2 Wood Aluminum 1x 3V BA-1 ● ● ⁃ ● ⁃   ⁃ ⁃ P/S (No Capacitor)     Link Link
1917 USA Camp Telephone Model A (EE-4) LB/CB 195x130x250 8.2 Wood Aluminum 1x 3V BA-1 ● ● ⁃ ● ⁃   ⁃ ⁃ P/S (With Capacitor) Western Electric Link Link Link
1917 USA Field Telephon Model 1917 (EE-3) LB/CB 230x135x260 8.2 Wood Aluminum 2x 3V BA-1 ● ● ● ● ⁃   ⁃ ⁃ P/S   Kellogg Switch and Supply Co. Yes Link Link
1918 USA Field Artillery Telephone (EE-5) LB 180x95x230 5 Leather Aluminum 1x 4,5V Flashlight ● ● ⁃ ● ⁃   ⁃ ⁃ P/S WE 1375B Western Electric   Link Link
1918 Sweden M/18 Artillery LB 290x110x240   Leather Wood   ● ● ⁃ ● ●   ⁃ ⁃ P/S         Link
1918 Sweden M/18 Infantery LB 230x110x240   Leather Wood   ● ● ⁃ ● ●   ⁃ ⁃ P/S         Link
1923 Czechoslovakia VZ 23 LB 270x105x220 6.3 Wood Wood 2x 1,5V ● ● ● ● ⁃   ⁃ ⁃ P/S     Yes   Link
1926 Germany Feldfernsprecher 26 LB/CB 280x100x220 6.4 Wood Wood 2x 1,5V IEC S4 ● ● ○ ● ○   ○ ⁃ P/S   C. Lorenz AG Link Link Link
1926 Sweden M/26 LB     Leather Wood   ● ● ⁃ ● ⁃   ⁃ ⁃ P/S         Link
1927 France TM 27 LB 214x202x184 6.2 Wood Wood 2x 1,5V TM No0 ● ● ⁃ ● ●   ⁃ ⁃ P/S     Yes   Link
1927 Poland AP-27 LB 280x160x170 6 Wood Wood 2x 1,5V ● ● ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined Updated but mostly identical Versions were AP-30/33/34   Yes   Link
1928 Russia UNA-F-28 LB 227x100x224 4.5 Wood Wood 2x 1,5V 3C ● ⁃ ● ● ⁃   ⁃ ⁃ P/S         Link
1928 Russia UNA-I-28 LB 227x100x224 6 Wood Wood 2x 1,5V 3C ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link Link
1930 Hungary 30M LB/CB 285x104x197 5 Wood Wood 2x 1,5V ● ● ● ● ○   ○ ⁃           Link
1930 Norway Modell 1930 LB 289x125x287 8 Wood Metal 2x 1,5V IEC S4 ● ● ⁃ ● ○   ○ ⁃ P/S   Elektrisk Bureau Yes Link Link
1931 Italy Guardafili Mod. 31 LB 230x127x270 7 Leather Aluminum/Bakelite 2x 1,5V ● ● ⁃ ● ○   ⁃ ⁃ P/S     Yes   Link
1931 Italy G.A. Mod. 1931 LB 318x140x240 8.1 Wood Wood 1x 3V ● ● ⁃ ● ○   ⁃ ⁃ P/S     Yes   Link
1931 Russia UNA-F-31 LB 285x100x240 4.7 Wood Wood 2x 1,5V 3C ● ⁃ ● ● ⁃   ⁃ ⁃ P/S         Link
1931 Russia UNA-I-31 LB 288x115x238 6.9 Wood Wood 2x 1,5V 3C ● ● ⁃ ● ⁃   ⁃ ⁃ P/S       Link Link
1932 France TM 32 LB 218x122x196 5 Metal Metal 2x 1,5V TM No0 ● ● ⁃ ● ● ● ⁃ ⁃ P/S     Link   Link
1932 Japan Type 92 LB 270x110x170 5.5 Leather/Canvas Wood 2x 1,5V (Parallel) ● ● ● ● ⁃   ⁃ ⁃       Yes Link Link
1932 Switzerland Armeetelephon Modell 32 LB/CB 330x140x240 9.5 Wood Light alloy 2x 1,5V IEC S4 ● ● ● ● ●   ○ ⁃ Induction coil/Buzzer combined   Albiswerk Link Link Link
1933 Germany Feldfernsprecher 33 LB 280x100x210 5.5 Bakelite Light alloy, Steel 1x 1,5V IEC S4 ● ● ⁃ ● ○   ○ ⁃ Anti-sidetone   Siemens & Halske Link Link Link
1933 Italy Tipo F Mod. 33 LB 190x140x203 3.6 Leather Metal 1x 4,5V ● ● ⁃ ⁃ ●   ⁃ ⁃ P/S
1933 Russia TAM LB/CB 360x145x270 11.4 Wood Wood 4x 1,5V 3C ● ● ● ● ⁃   ⁃ ⁃ Differential microphone Long range transmission (250km)     Link Link
1934 Italy G.A. Mod. 34 LB 290x140x250 9 Metal Metal 2x 1,5V ● ● ⁃ ⁃ ●   ⁃ ⁃ P/S         Link
1934 Yugoslavia M34 LB 160x140x260 6 Metal Metal 1x 1,5V ● ● ⁃ ● ●   ⁃ ⁃ P/S   Ericsson Colombes Yes
1934 Spain EE107 (C-03101) LB 330x220x160   Wood Wood   ● ● (GR.25) ● -   ⁃ ⁃ P/S Models GR.19, GR.24, GR.25 (with buzzer) Standard Eléctrica     GR.19 GR.24 GR.25
1935 Austria M35 LB/CB 275x115x230 5.5 Wood Metal 2x 1,5V IEC S4 ● ● ● ● ○   ○ ⁃ P/S   Kapsch Link   Link
1935 Belgium Bell LB 240x120x185 6.4 Metal Metal 2x 1,5V ● ● ● ● ⁃ ○ ⁃ ⁃ Anti-sidetone Used also in Spain: C-2730/AP209000 Bell Antwerpen (BTMC Catalog 1936 # 2730-A) Yes Link Link
1935 Belgium ATEA LB 250x120x185 7.3 Metal Metal 2x 1,5V ● ● ● ● ⁃ ○ ⁃ ⁃ Anti-sidetone   ATEA Yes Link
1935 Czechoslovakia VZ 35 LB 280x125x230 6.7 Wood Wood 2x 1,5V ● ● ● ● ⁃   ⁃ ⁃ P/S     Yes   Link
1936 France TM 36 LB/CB 200x160x200 5 Metal Metal 2x 1,5V ● ● ⁃ ● ●   ● ⁃ P/S         Link
1936 Poland AP-36 LB 260x90x180 4 Metal Bakelite 1x 1,5V ● ● ⁃ ● ○   ⁃ ⁃ Anti-sidetone         Link
1936 GB F. Mk. I. LB/CB 300x180x200 7.8 Wood Cast-Alloy 2x 1,5V Size S/X ● ● ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined     Link Link Link
1937 Sweden M/37 LB/CB 260x86x187 4.2 Bakelite Light-Alloy 2x 1,5V D ● ● ● ● ●   ○ ⁃ Anti-sidetone Later updated to m/37-47 and to TFNAPP MT Ericsson Link Link Link
1937 USA EE-8-[A,B] LB/CB 200x90x250 5.3 Leather, Canvas Light alloy, Steel 2x 1,5V D ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone   Western Electric Link Link Link
1938 USA TP-3-T1 (TP-3, 1944) Sound 200x90x250 4.3 Leather (Canvas) Light alloy ⁃ ● ● ⁃ ● ⁃   ⁃ ⁃ Sound powered TP-3: Neon lamp ring indicator     Link Link
1938 Finnland P-1-8 (VPAT) LB 280x105x240 6.6 Wood Wood 2x 1,5V ● ● ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined Made by Tartu in Estonia Tartu Link   Link
1939 France TM 39 LB     Bakelite Bakelite   ● ● ⁃ ● ●   ⁃ ⁃           Link
1939 GB D. Mk. V. LB 225x150x115 4.4 Aluminum Bakelite 2x 1,5V Size S/X ● ⁃ ● ● ●   ⁃ ⁃ Induction coil/Buzzer combined     Yes   Link
1939 Hungary 39M LB 290x110x200 3.5 Bakelite Bakelite 2x 1,5V ⁃ ⁃ ● ● ⁃   ⁃ ⁃       Yes   Link
1939 Russia TABIP-2 Sound 220x100x110 1.1 Canvas Bakelite ⁃ ⁃ ⁃ ⁃ ● ⁃   ⁃ ⁃ Sound powered Handset only device     Link Link
1939 Russia TABIP-1 Sound 262x103x160 4.1 Aluminum Aluminum ⁃ ● ● ⁃ ● ⁃   ⁃ ⁃ Sound powered       Link Link
1940 GB F. Mk. II. LB/CB 300x180x200 5 Wood Bakelite 2x 1,5V Size S/X ● ● ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined     Link Link Link
1940 GB H. Mk. II Sound 300x180x200   Wood Bakelite ⁃ ● ● ⁃ ● ⁃   ⁃ ⁃ Sound powered Same form factor that set F       Link
1940 Italy Regia Aeronautica LB 270x120x220 6 Metal Metal 2x 1,5V ● ● ● ● ⁃ ○ ⁃ ⁃     FACE / FATME Yes   Link
1940 USA EE-108 Sound 200x90x250 4.3 Leather Light alloy ⁃ ● ● ⁃ ● ⁃   ⁃ ⁃ Sound powered   Connecticut Telephone and Electrical Company Link Link Link
1941 GB L. LB/CB 255x130x130 4.5 Aluminum Aluminum 2x 1,5V Size S/X ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone     Yes Link
1941 GB H. Mk. III Sound 255x130x130 4.5 Aluminum Aluminum ⁃ ● ● ⁃ ● ⁃   ⁃ ⁃ Sound powered Same form factor that set L   Yes   Link
1941 Hungary 41M TBK-1 LB/CB 285x100x195 5 Bakelite Metal 2x 1,5V ● ● ⁃ ● ○   ⁃ ⁃ Anti-sidetone     Yes   Link
1941 Russia TA-41 LB 286x98x140 2.9 Wood Wood 1x 1,5V 3C ⁃ ⁃ ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined         Link
1941 Russia PF-1 LB     Wood Wood 2x 1,5V 3C ● ● ⁃ ● ⁃   ⁃ ⁃ P/S         Link
1941 Switzerland Feldtelephon Modell 41 LB/CB 320x145x260 9.1 Leather Light alloy 2x 1,5V IEC S4 ● ● ● ● ●   ○ ⁃ Induction coil/Buzzer combined   Autophon Link   Link
1941 Argentina TTA 5 LB 290x180x150 4 Leather Wood 2x 1,5V ● ● ⁃ ● ○   ⁃ ⁃ P/S     Yes   Link
1942 Italy Modell 42 LB 280x120x220 5.5 Bakelite Bakelite 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone     Yes   Link
1942 Japan Model 2 LB 241x127x216 5.5 Leather Wood 1x 3V ● ● ⁃ ● ⁃   ⁃ ⁃         Link
1942 Russia TAT-F LB 270x68x70 1.5 Canvas Plastic 2x 1,5V ⁃ ⁃ ● ● ⁃   ⁃ ⁃ Induction coil/Buzzer combined Handset only device     Link Link
1942 Russia UNA-F-42/43 LB 285x105x155 3.2 Wood Wood 1x 1,5V 3C ● ⁃ ● ● ⁃   ⁃ ⁃ 1943: Anti-sidetone         Link
1942 Finnland P-1-1 (VPAP) LB 270x92x197 4.9 Bakelite Metal 2x 1,5V ● ● ⁃ ● ○   ⁃ ⁃ Anti-sidetone   Puhelinteollisuus Oy     Link
1942 Germany Feldfernsprecher b Sound 250x100x210   Bakelite Bakelite ⁃ ● ● ⁃ ● ○   ⁃ ⁃ Sound powered   Siemens & Halske, Prototype only?     Link
1943 Germany OB 43 LB 280x100x215 4.2 Bakelite Bakelite 1x 1,5V IEC S4 ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone   Mix & Genest Link   Link
1943 Russia TAI-43 LB 280x110х210 4.6 Wood/Bakelite Bakelite 1x 1,5V 3C ● ● ⁃ ● ●   ⁃ ⁃ Anti-sidetone Polish AP48 and MB-66 are identical   Yes (MB-66) Link Link
1943 Russia UNA-I-42/43 LB 286x123x185 5 Wood Wood 1x 1,5V 3C ● ● ⁃ ● ⁃   ⁃ ⁃ 1943: Anti-sidetone         Link
1943 Russia 2005-W LB 280x115x230 5.4 Wood Metal 2x 1,5V 2C ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone Repackaged US EE-8 to be used with russina battery types       Link
1943 Russia UNA-FI-43 LB 285x115x235 7.6 Wood Wood 2x 1,5V 3C ● ● ● ● ⁃   ○ ⁃ Anti-sidetone         Link
1944 Italy M/Du LB     Metal Metal 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃     Ducati     Link
1944 Russia IAA-44 LB 250x100x250 6.1 Metal Metal 2x 1,5V 3C ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone Repackaged US EE-8 to be used with russian battery types   Yes   Link
1945 GB J. LB 255x130x130 4.1 Metal Metal 2x 1,5V Size S/X ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone     Yes Link
1945 Spain C-30101 LB 295x110x235 7 Wood Metal 1x 3V ● ● ⁃ ● ○ ○ ⁃ ⁃ Anti-sidetone   Standard Eléctrica Link   Link
1945 France AT1 LB 260x180x125 4.6 Bakelite Bakelite 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone LB only   Yes   Link
1945 France AT2 LB/CB 260x180x125 4.6 Bakelite Bakelite 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone Can be switched between LB and CB   Yes   Link
1946 Italy D.Mk.VI LB 225x150x115 4.4 Aluminum Bakelite 2x 1,5V Size S/X ● ● ⁃ ● ●   ⁃ ⁃ Anti-sidetone British D.Mk.V with Magneto instead of Buzzer   Link   Link
1947 Switzerland Feldtelephon Modell 47 LB/CB 320x145x260 9.1 Leather Light alloy 2x 1,5V IEC S4 ● ● ⁃ ● ●   ○ ⁃ Anti-sidetone   Autophon Link   Link
1947 Switzerland Armeetelephon Modell 47 LB/CB 330x140x240 9.5 Wood Light alloy 2x 1,5V IEC S4 ● ● ⁃ ● ●   ○ ⁃ Anti-sidetone   Albiswerk Link Link Link
1949 Yugoslavia PTI-49 LB     Bakelit Metal 2x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone   Iskra Yes   Link
1950 Czechoslovakia TP 25 LB 270x100x170 3.8 Bakelite Bakelite 1x 1,5V IEC S4 ● ● ⁃ ● ⁃   ⁃ ⁃ Anti-sidetone   Tesla Link   Link
1950 Hungary TBK-2 LB/CB 250x152x196   Metal Metal 2x 1,5V ● ● ⁃ ● ○   ⁃ ⁃ Anti-sidetone         Link
1950 Switzerland Feldtelephon Modell 50 LB/CB 150x100x225 2.6 Canvas Bakelite 1x 1,5V D ● ● ⁃ ● ○   ○ ⁃ Induction coil/Ringer combined   Albiswerk Link Link Link
1951 Denmark HSGT FTLF M/51 LB/CB 260x86x187 4.5 Bakelite Metal 2x 1,5V D ● ● ⁃ ● ●   ● ⁃ Anti-sidetone   Ericsson Yes   Link
1951 Denmark HSGT FTLF M/51 L LB/CB 350x120x230 6 Leather Wood 2x 1,5V D ● ● ⁃ ● ●   ● ⁃ Anti-sidetone Is also a 4 line switchboard, is basically a slightly updated M. 1909/14 with the addition of CB/Aut. support Ericsson Yes   Link
1952 USA TA-43/PT LB/CB 280x180x100 4.3 Canvas Cast-Alloy 2x 1,5V D ● ● ⁃ ● ⁃   ⁃ ● Anti-sidetone   Western Electric Link Link Link
1953 Germany (DDR) Feldfernsprecher 53 LB/CB 290x110x170 5.2 Bakelite Metal 2x 1,5V ● ● ⁃ ● ●   ○ ⁃ Anti-sidetone Battery can be switched between 2x 1,5V parallel or in series Fernmeldewerk Nordhausen Yes   Link
1953 Switzerland Armeetelephon Modell 53 LB/CB 230x85x160 2.6 Steel Bakelite 1x 1,5V D ● ● ⁃ ● ○   ○ ⁃ Induction coil/Ringer combined   Albiswerk Link Link Link
1954 Germany (BRD) Feldfernsprecher OB/ZB LB/CB 270x120x170 4.3 Bakelite Bakelite 2x 1,5V D ● ● ⁃ ● ○   ○ ⁃ Anti-sidetone   SEL Yes Link Link
1955 Netherlands TA-3017 LB/CB 160x240x95 4.5 Canvas Bakelite 2x 1,5V D ● ● ⁃ ● ⁃   ○ ⁃ Anti-sidetone   Krone (Germany)   Link Link
1955 USA TA-1/PT Sound 260x90x130 1.3 Plastic Cast-Alloy ⁃ ● ● ⁃ ● ⁃   ⁃ ⁃ Sound powered     Link Link Link
1956 USA TA-312/PT LB/CB 280x180x100 4.3 Canvas Cast-Alloy/Molded Plastic 2x 1,5V D ● ● ⁃ ● ⁃   ○ ● Anti-sidetone Optional DTMF Dial   Link Link Link
1956 USA TA-341()/PT LB/CB 250x230x100 4.5 Fiberglass Fiberglass 5x 1,5V C ● ● ⁃ ● ⁃   ● ● Transistorised 4-Wire, DTMF, only introduced as field test, never procured as standard, later introduced as TA-341/TT desk set Stromberg-Carlson Yes   Link
1956 Russia TAM-56 LB                                 Yes
1957 Russia TA-57 LB/CB 222x165x80 3 Bakelite Bakelite 1x 10V ● ● ⁃ ● ○   ⁃ ⁃ Transistorised     Yes Link Link
1958 Denmark Felttelefon HMAK Type FT58/72 LB/CB 265x105x170 4.5 Canvas Cast-Alloy 2x 1,5V D ● ● ⁃ ● ⁃   ● ● Anti-sidetone   ITT Kirk Yes   Link
1963 Germany (DDR) Feldfernsprecher 63 LB/CB 280x120x132 4.2 Bakelite Bakelite 5x 1,5V AAA ● ● ⁃ ● ●   ○ ⁃ Transistorised   RFT Yes Link Link
1963 Yugoslavia M-63 LB/CB 250x95x140 3 Metal Metal 2x 1,5V D ● ● ⁃ ● ⁃   ○ ● Anti-sidetone   Iskra Link Link Link
1965 China T 65 LB 200x105x225 2.6 Leather Fibre 2x 1,5V D ● ● ⁃ ● ○   ⁃ ⁃ Anti-sidetone T65-1 with plastic housing   Yes   Link
1965 Sweden Telefonapparat 386 LB/CB 280x187x245 6.6 Metal Metal 4x 1,5V D ● ● ⁃ ● ⁃   ● ⁃ Transistorised   Svenska AB Trådlös Telegrafi (SATT) Yes   Link
1967 Russia TAP-67 LB/CB 240x100x140 2 Bakelite Bakelite 1x 9,6V ● ● ⁃ ● ○   ○ ⁃ Transistorised There seems to be an earlier Version, the TAP-64, only ever seen one specimen (Bulgarian version, from a private collection)   Yes   Link
1968 China CX-2 LB ⁃ ⁃ Bakelite Bakelite ⁃ ● ● ⁃ ● ○   ⁃ ⁃ Anti-sidetone     Yes   Link
1972 Romania TC-72 LB/CB 245x90x165 3.5 Plastic Plastic 3x 1,5V C ● ● ⁃ ● ⁃   ○ ⁃ Transistorised     Yes   Link
1973 Norway TP-6N LB/CB 260x85x65 1.8 Canvas Aluminum 3x 1,5V D ● ● ⁃ ● ⁃   ○ ⁃ Transistorised   Elektrisk Bureau Link Link Link
1975 GB PTC 404 LB/CB 210x260x60 2.8 Canvas Cast-Alloy 4x 1,5V D ● ● ⁃ ● ⁃   ⁃ ● Transistorised   Racal Yes Link
1975 Sweden 390 MT LB 190x136x70 1 Plastic Plastic 2x 1,5V C ⁃ ⁃ ● ● ⁃   ⁃ ● Transistorised       Link Link
1977 Russia TAP-77 LB/CB     Plastic Plastic 6x 1,5V ● ● ⁃ ● ○   ○ ⁃ Transistorised
1977 USA TA-838/TT LB/CB 245x150x140 3 ⁃ Plastic 4x 1,5V C ● ● ⁃ ● ⁃   ● ● Transistorised 2- or 4-Wire, DTMF, not compatible with "classic" 2-wire magneto signalling   Yes Link Link
1978 Finnland P-78 LB         3x 1,5V D ● ● ⁃ ● ⁃   ⁃ ● Transistorised   Ericsson     Link
1980 Austria SFT800 F-27-0 LB/CB 270x150x140 3.6 Plastic Plastic 2x 1,5V D ● ● ⁃ ● ⁃   ● ● Transistorised   Siemens Link Link Link
1980 Israel TA-427 LB/CB 240x125x95 2.1 Plastic Plastic 3x 1,5V D ● ● ⁃ ● ⁃   ○ ● Transistorised There is also a 2/4 wire version Tadiran   Link Link
1980 Italy TA-622A LB/CB 250x105x60 2 Plastic Plastic 3x 1,5V D ● ● ⁃ ● ⁃   ○ ● Transistorised     Yes   Link
1980 Romania F-1603 LB/CB     Plastic Plastic 3x 1,5V C ● ● ⁃ ● ⁃   ○ ⁃ Transistorised         Link
1980 Yugoslavia PTE-1 LB/CB 250x100x160   Canvas Metal 2x 1,5V C ● ● ⁃ ● ⁃   ⁃ ⁃     Etas Split     Link
1982 Poland AP-82 LB/CB 250x100x160 2.8 Plastic Plastic 3x 1,5V C ● ● ⁃ ● ⁃   ⁃ ⁃ Transistorised There seem to exist an updated but mostly similar AP-92       Link
1988 Russia TA-88 LB/CB 230x165x90 3 Plastic Plastic 6x 1,5V ● ● ⁃ ● ○   ⁃ ⁃ Transistorised         Link
1990 Spain TSB-184/OP Sound 260x90x130 1.3 Canvas Plastic ⁃ ● ● ⁃ ● ⁃   ⁃ ⁃ Sound powered Copy of a TA-1/PT Amper Programas     Link
1989 France AT-75A TLEE 89 LB/CB 270x150x120 4 Plastic canvas Cast-Alloy 4x 1,5V ● ● ⁃ ● ⁃   ⁃ ⁃ Transistorised     Link   Link
1994 GB PTC 414 LB/CB 162x268x112 1.8 Plastic Plastic 4x 1,5V C ● ● ⁃ ● ⁃   ● ● Transistorised DTMF & Pulse; NSN 5805-99-786-1530 Racal RA2000 Link Link Link
1995 Austria TA-603/GY LB/CB     Plastic Plastic 3x 1,5V C ● ● ⁃ ● ⁃   ● ● Transistorised DTMF & Pulse; NSN 5805-12-386-8224     Link
2000 USA TA-1088/PT LB/CB 120x110x240 1.7 Plastic Plastic 3x 1,5V C ● ● ⁃ ● ⁃ ⁃ ● ● Transistorised DTMF & Pulse; no indication found that ever in use by any US military forces     Link
2003 Japan OHT-2003M LB/CB           ● ● ⁃ ● ○   ⁃ ●     Oki Electric Industry     Link

Table key

Some important general sources

Creative Commons Attribution-ShareAlike 4.0 International License

Home
